The 12.1 inch industrial panel computer AMG-12PPC01TA from Amongo is a good option for industrial application with features as below:
Industrial-grade LCD panels with perfect image quality and wide viewing angles, low power consumption LED backlight;
High performance processor, fast access hard drives, stable power supplies for trouble-free function in long time workload;
Various touchscreen technologies, like PCAP, Resistive etc.;
Robust structure design with metal bezel for front IP65 waterproof;
Easy installation for panel mount or embedded mount;
Meet with requested sustainability tests and reliability test to survive in the toughest application environment
Model Name | AMG-12PPC01TA |
CPU | Intel Celeron CPU J1900 1.99GHz |
RAM | DDRIII 4GB |
SSD | 128G |
VGA ports | 1x VGA ports |
COM ports | 1x COM ports |
USB ports | Default 3xUSB 2.0(1xUSB 3.0) |
Ethernet | 1x 10/100/1000BASE-T Gigabit Ethernet |
Audio | Mic-in, Line-out |
WiFi | 802.11n WiFi |
Screen Size | 12.1" |
Active Area(mm) | 245.76(H)x184.32(V) |
Display Resolution | 1024x768 |
Pixel Pitch(mm) | 0.24(H)x0.24(V) |
Display Mode | Normally white |
Display Color | 16.2M/262K |
Brightness(cd/㎡) | 500 |
Contrast Ratio | 700:1 |
Viewing Angles | 160(H);160(V) |
Response Time | 35ms |
Touch Screen | Resistive touch(5 wire) |
Operating Temperature | -30～85℃ |
Storage Temperature | -30～85℃ |
Relative Humidity | 5[%RH]～90[%RH] |
