PCAP Multi-touch screen
Full flat fillet design
IP 65 waterproof,dust-proof,vandal-proof
Support for embedded,VESA installation
Stable quality through high reliability testing
Application:
AFC/Recyling machine/ Industrial automation etc
| Technical Specification | |
| LCD | |
| Model Name | AMG-10IPTE03N1 |
| Screen Size | 10.4" |
| Active Display Area(mm) | 211.2(H)x158.4(V) |
| Pixel Pitch(mm) | 0.264(H)x0.264(V) |
| Display Mode | Normally Black |
| Display Resolution(pixel) | 1920x1080 |
| Contrast Ratio | 3000:1 |
| Display Color | 16.7M |
| Brightness | 1000nits |
| Backlight | LED |
| Viewing Angles（CR=10） | 178(H);178(V) |
| Response Time（Typ.Tr+Tf） | 18ms |
| Optional | |
| Touch Screen | PCAP Touch（10 points） |
| Light Sensor | Optional |
| Privacy Film | Optional |
| I/O Interface | |
| Signal Connector | VGA/DVI |
| Power Consumption | DC 12V |
| Touch Controller | USB |
| Mechanical | |
| Dimension(VxHxT)mm | 306.6*230.1*57 |
| Environmental | |
| Operating Temperature | -20~70℃（non-condensation） |
| Storage Temperature | -30~80℃（non-condesation） |
| Relative Humidity | 5~90(% RH) |
