Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 long time running;
Durable mechanical design to meet tough environmental conditions and requirements;
Bezel-less full flat surface, front waterproof, dust proof, vandal proof;
Support for embedded or VESA mounting, easy for maintenance;
Customization service available;
Model Name | AMG-32OPZY01T1 |
Screen Size | 31.5" |
Active Display Area (mm) | 698.4(H)x392.85(V) |
Pixel Pitch (mm) | 0.12125(H)x0.36375(V) |
Display Mode | Normally black |
Display Resolution (pixel) | 1920x1080 |
Contrast Ratio | 1200:1 |
Display Color | 16.7M |
Brightness (CD/㎡) | 300nits |
Backlight | LED |
Viewing Angles (CR =10) | 178(H);178(V) |
Response Time(Typ.Tr+Tf) | 8ms |
Signal Connector | VGA/DVI-D/HDMI/USB |
Power Consumption | AC 220V |
Dimension(VxHxT) | 747x441x58 |
Operating Temperature | 0~50℃ |
Storage Temperature | -20~60℃ |
Relative Humidity | 5(%RH)~90(%RH) |
Touch Screen | PCAP Touch(10 points) |
