PCAP Multi-touch screen
Full flat surface,aluminum profile design
Surface hardness MoHs 7
IP65 waterproof,vandal-proof,dust-proof
Stale quality through high reliability testing
Application:
AFC/Industrial automation/Kiosk etc
| Technical Specification | |
| LCD | |
| Model Name | AMG-43IPTP01T1 |
| Screen Size | 43" |
| Active Display Area(mm) | 940.8(H)x529.2(V) |
| Pixel Pitch(mm) | 0.16335(H)x0.49005(V) |
| Display Mode | Normally Black |
| Display Resolution(pixel) | 1920x1080 |
| Contrast Ratio | 1200:1 |
| Display Color | 16.7M |
| Brightness | 400nits |
| Backlight | LED |
| Viewing Angles（CR=10） | 178(H);168(V) |
| Response Time（Typ.Tr+Tf） | 8ms |
| Optional | |
| Touch Screen | PCAP Touch（10 points） |
| Light Sensor | Optional |
| Privacy Film | Optional |
| I/O Interface | |
| Signal Connector | VGA/DVI/HDMI |
| Power Consumption | DC 220V |
| Touch Controller | USB |
| Mechanical | |
| Dimension(VxHxT)mm | 1016*610*60 |
| Environmental | |
| Operating Temperature | 0~50℃（non-condensation） |
| Storage Temperature | -20~60℃（non-condesation） |
| Relative Humidity | 5~90(% RH) |
