Resistive Touchscreen
Plastic frame，rugged steel housing
High reliability testing，stable performance
High brightness/light sensor optional
Application:
AFC/ Non-cash equipment / Kiosk etc
| Technical Specification | |
| LCD | |
| Model Name | AMG-15IPAM01T1 |
| Screen Size | 15" |
| Active Display Area(mm) | 344.16(H)x193.59(V) |
| Pixel Pitch(mm) | 0.17925(H)x0.17925(V) |
| Display Mode | Normally White |
| Display Resolution(pixel) | 1920x1080 |
| Contrast Ratio | 400:1 |
| Display Color | 16.7M |
| Brightness | 270nits |
| Backlight | LED |
| Viewing Angles（CR=10） | 140(H);120(V) |
| Response Time（Typ.Tr+Tf） | 8ms |
| Optional | |
| Touch Screen | Resistive Touchscreen |
| Light Sensor | Optional |
| I/O Interface | |
| Signal Connector | VGA/DVI/AV/HDMI |
| Power Consumption | DC 12V |
| Touch Controller | USB |
| Mechanical | |
| Dimension(VxHxT)mm | 390*240.1*42 |
| Environmental | |
| Operating Temperature | 0~50℃（non-condensation） |
| Storage Temperature | -20~60℃（non-condesation） |
| Relative Humidity | 5~90(% RH) |
