Branded LCD panels with perfect image quality and wide viewing angles, industrial-grade components adopted for a reliable 24/7 long time running;
Durable mechanical design to meet tough environmental conditions and requirements;
Molded side frame integrated with PCAP touchscreen for easy installation and maintenance
True flat surface, front IP65 waterproof, dust proof, vandal proof;
Customization service available
Model Name | AMG-14IPGD01T1 |
Screen Size | 14" |
Active Display Area (mm) | 309.312(H)x173.988(V) |
Pixel Pitch (mm) | 0.264(H)x0.264(V) |
Display Mode | Normally white |
Display Resolution (pixel) | 262K |
Contrast Ratio | 1920x1080 |
Display Color | 800:1 |
Brightness (CD/㎡) | 250nits |
Backlight | LED |
Viewing Angles (CR =10) | 170(H);170(V) |
Response Time(Typ.Tr+Tf) | 30ms |
Signal Connector | VGA/DVI-D/USB |
Power Consumption | DC 12V |
Dimension(VxHxT) | 339x212x33 |
Operating Temperature | 0~50℃ |
Storage Temperature | -20~60℃ |
Relative Humidity | 5(%RH)~90(%RH) |
Touch Screen | PCAP Touch(10 points) |
