Resistive Touchscreen
Plastic frame，rugged steel housing
High reliability testing，stable performance
High brightness/light sensor optional
Application:
AFC/ Non-cash equipment / Kiosk etc
| Technical Specification | |
| LCD | |
| Model Name | AMG-15IPNC01N2 |
| Screen Size | 15" |
| Active Display Area(mm) | 304.128(H)x228.096(V) |
| Pixel Pitch(mm) | 0.297(H)x0.297(V) |
| Display Mode | Normally White |
| Display Resolution(pixel) | 1024x768 |
| Contrast Ratio | 700:1 |
| Display Color | 16.2M |
| Brightness | 350nits |
| Backlight | LED |
| Viewing Angles（CR=10） | 160(H);140(V) |
| Response Time（Typ.Tr+Tf） | 8ms |
| Optional | |
| Touch Screen | PCAP Touch(10 points) |
| Light Sensor | Support |
| Tempered glass | Support |
| I/O Interface | |
| Signal Connector | VGA/DVI |
| Power Input | DC 24V |
| Touch Controller | USB |
| Mechanical | |
| Dimension(VxHxT)mm | 363*280*76.5 |
| Environmental | |
| Operating Temperature | -30~85℃（non-condensation） |
| Storage Temperature | -30~85°C（non-condesation） |
| Relative Humidity | 5~90(% RH) |
